6 Piston Motorsport Brake Caliper

RCS6CEJ2

Description

Brypar  Sport Series motorsport brake calipers have been specifically designed as an entry level motorsport brake caliper. Machined from solid billet the 2 piece design uses a fixed bridge to increase overall stiffness, while using widely available pad shape allowing the user a wide range of pad compound choice. Designed to use an 18mm pad with up to a 36mm width disc between 350-380mm, the sport series is a true motorsport caliper without the motorsport caliper price. Aluminium pistons with integrated cooling, internal fluid lines, stainless steel wear plates, high temperature seals and a hard anodise finish all come as standard.

Specification

Disc Diameter - mmPiston Sizes - mmDisc thickness - mmPL Dimension - mmMounting & OffsetPad ShapeWeight
Max = Ø380.0
Min = Ø350.0
27.0 x 2
32.0 x 2
38.0 x 2
Max = 36.0
Min = 34.0
63.0Radial mounting
210mm x 38mm
CP3905D54
18mm thickness
3.9kg
SKU: RCS6CEJ2 Categories: ,

Contact us for pricing
